Compare all models in the BMP Series:
| Specification | B-24 | B-34 | B-44 |
|---|---|---|---|
| Sealing Width | 24โ (60.96 cm) | 34โ (86.36 cm) | 44โ (111.76 cm) |
| Maximum Product Width | 20โ (50.8 cm) | 30โ (76.2 cm) | 40โ (101.6 cm) |
| Standard Product Height | 16โ (41 cm) | 16โ (41 cm) | 16โ (41 cm) |
| Production Speed | Dependent on application | Dependent on application | Dependent on application |
| Construction | Painted steel | Painted steel | Painted steel |
| Machine Dimensions (L ร W ร H) | 65โ ร 52โ ร 83โ(165 ร 132.8 ร 210.8 cm) | 65โ ร 62โ ร 83โ(165 ร 157.4 ร 210.8 cm) | 65โ ร 72โ ร 83โ(165 ร 182.8 ร 210.8 cm) |
| Weight (Crated) | 700 lbs (317.5 kg) | 900 lbs (408.2 kg) | 1100 lbs (498.9 kg) |
| Air Requirement | 80 PSI / 10 CFM | 80 PSI / 10 CFM | 80 PSI / 10 CFM |
| Infeed | Manual | Manual | Manual |
| Discharge Conveyors | Adjustable speed | Adjustable speed | Adjustable speed |
| Power Requirement | 120 V, 15A, 1 Phase | 120 V, 15A, 1 Phase | 120 V, 15A, 1 Phase |
| Controls | Digital PID temperature controlSpeed adjustmentSeal adjustment | Digital PID temperature controlSpeed adjustmentSeal adjustment | Digital PID temperature controlSpeed adjustmentSeal adjustment |
| Shrink Tunnel Options | Multiple single-zone & double-zone options | Multiple single-zone & double-zone options | Multiple single-zone & double-zone options |
Key Features and Benefits:
Damark Semi-Automatic Shrink Wrap Systems are thoughtfully designed and intuitive to use and come equipped with pneumatic Teflon-coated sealing heads, twin safety push-button controls, digital PID temperature controls and precise seal adjustment. Seals are attractive, strong and secure for high-value, cost-effective packaging.
- Digital temperature controls
- Precise seal adjustment
- Teflon-coated sealing head
- Adjustable speed discharge conveyors
- Easy thread, quick-change film system
- Large capacity film rolls
- Heavy-duty construction
- All parts UL/CSA approved
- Locking casters
- Numerous custom options available
Optional Additions:
- Manual Product Pusher Kit
- Broken Seal Alarm
- Builds for Large Products
- Low Film Indicator
For more information about this machine and other sleeve/bundle wrapping options, pleaseย contact usย atย (416) 299-0960, and one of our customer service representatives will be happy to assistย you with whatever you need.
